Soprano cornet, E-flat, low pitch
Maker
C. G. Conn
Date1892 ca.
Place MadeElkhart, Indiana, United States, North America
Place MadeWorcester, Massachusetts, United States, North America
ModelLeaders' Soprano Eb Wonder Cornet
Serial No.31020
SignedEngraved on bell: MADE / BY / C. G. CONN / ELKHART, IND. / WORCESTER. / MASS.MarkingsStamped on left of second valve casing: 0 / 31020 / PAT. JUNE / 15. 1886
Stamped on valve stems: 31020
Stamped on valve casings, stems and largest guide lug, respectively: 1, 2, 3
DescriptionSilver-plated brass, mother-of-pearl finger buttons, single loop, telescopic tuning slide at leadpipe with ligature screw, three Périnet valves (1, ½, 1½), top-sprung, spring inside hollow stem, alignment by three unequal lugs on spring anchor plate, nickel-plated brass pistons, single water key at first bow, windway 3-2-1
Telescopic silver-plated brass tuning slide (probably not original).
The Leaders' Model Wonder Soprano Cornet in E-flat was introduced during the Worcester era and features US patent no 343,888 from June 15, 1886. The characertistic of this patent was the smooth, continuous windway, achieved by diagonal intervalve tubing between the third and the second valve.
DimensionsHeight: 309 mm
Tube length: 938 mm, 948 mm
Bore diameter (initial and minimum, valve slides): 10.2 mm, 10.65 mm (0.419 inches)
Bore diameter (tuning slide, initial, minimum): 9 mm, 8.8 mm
Bell diameter: 121 mm or 4 3/4 inches
ProvenancePurchased from Steve Dillon, Woodbridge, New Jersey, in 1988.
Published ReferencesSabine Katharina Klaus, Trumpets and Other High Brass: A History Inspired by the Joe R. and Joella F. Utley Collection. Volume 4: The Heydey of the Cornet (Vermillion, SD: National Music Museum, 2022), pp. 172-73, 288.
Credit LineJoe R. and Joella F. Utley Collection, 1999
Object number06949
